Parameters:
model |
input speed r/min |
reduction ratio (i ) |
transfer ability kW/r/min |
Rated thrust (kN) |
Center distance (mm ) |
length x width x height (mm ) |
net weight (kg ) |
Manipulation type |
Link flywheel |
connection housing |
Input and output steering when following the train |
HC600A |
1000-2100 |
2.00 |
0.490 |
90 |
320 |
745 ×1214 ×1126 |
1300 |
Push-pull flexible shaft Electronic control Air control |
SAE21 18 16 14 Domestic machine Φ505 |
SAE00 01 no cover |
on the contrary |
HCD600A |
1000-2100 |
4.18 4.434.705.00 |
0.490 |
90 |
415 |
745 ×1214 ×1271 |
1550 |
Push-pull flexible shaft Electronic control Air control |
SAE21 18 16 14 Domestic machine Φ505 |
SAE00 0 1 no cover |
on the contrary |
5.44 |
0.450 |
||||||||||
5.71 |
0.430 |
||||||||||
HCT600A |
1000-2100 |
6.06 |
0.450 |
90 |
415 |
821 ×1214 ×1271 |
1650 |
Push-pull flexible shaft Electronic control Air control |
SAE21 18 16 14 Domestic machine Φ505 |
SAE00 0 1 no cover |
same |
6.49 |
0.419 |
||||||||||
6.97 |
0.390 |
||||||||||
7.51 |
0.363 |
||||||||||
8.04 |
0.338 |
||||||||||
8.66 |
0.314 |
||||||||||
9.35 |
0.291 |
||||||||||
HCT600A/1 |
1000-2100 |
7.04 7.69 8.23 8.82 9.47 |
0.441 |
140 |
500 |
878 ×1224 ×1346 |
1700 |
Push-pull flexible shaft Electronic control Air control |
SAE21 18 16 14 Domestic machine Φ505 |
SAE00 0 1 no cover |
same |
10.10 10.80 |
0.375 |
||||||||||
11.65 |
0.353 |
||||||||||
12.57 |
0.331 |
||||||||||
13.64 |
0.272 |
||||||||||
14.44 |
0.257 |
||||||||||
15.91 |
0.204 |
||||||||||
HCT650/2 |
1000-2100 |
9.51 |
0.49 |
160 |
550 |
966 × 1224 × 1515 |
2230 |
Push-pull flexible shaft Electronic control Air control |
SAE211816 Domestic machine Φ505 |
SAE000 no cover |
same |
10.06 |
|||||||||||
10.45 |
0.483 |
||||||||||
11.03 |
|||||||||||
11.46 |
0.452 |
||||||||||
11.98 |
|||||||||||
12.52 |
0.445 |
||||||||||
13.09 |
|||||||||||
13.64 |
0.414 |
||||||||||
14.10 |
|||||||||||
14.48 |
0.402 |
||||||||||
15.01 |
0.389 |
||||||||||
15.55 |
0.366 |
||||||||||
15.98 |
0.329 |
||||||||||
16.42 |
0.32 |
||||||||||
16.97 |
0.309 |
||||||||||
17.44 |
0.301 |
||||||||||
18.06 |
0.29 |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
