  • Diesel-driven single wheel Anchor windlass

Diesel-driven single wheel Anchor windlass

No.Anchor windlass 09
Diesel-driven single wheel Anchor windlass ①Available for Chain Size Dia.12.5mm-90mm AM2& AM3; ②Drive: Electro-hydraulic pump power station; ③Structure: Three gypsy wheel; ④Clutch: Manually operated Jaw Clutch; ⑤Brake: Manually operated Band Br
  • Diesel-driven single wheel Anchor windlass

Desciption

Diesel-driven single wheel Anchor windlass


1、Available for Chain Size Dia.12.5mm~90mm AM2& AM3;
2、Drive: Electric Motor;
3、Structure: Single gypsy wheel with one warping head;
4、Clutch: Manually operated Jaw Clutch;
5、Brake: Manually operated Band Brake;
6、Control: Local;
7、With Master controller& Electric Cabinet;
8、Painting: As per customer's requirement;
9、Ship Class certification: BV, RINA, CCS, LR, GL-DNV, ABS, IRS, CR; Working load calculation formula(when anchorage depth≤82.5m): For grade 1 anchor chain:F1=37.5d2; For grade 2 anchor chain:F2=42.5d2; For grade 3 anchor chain:F3=47.5d2; Here,'d' is the dia. Of anchor chain;
Overload calculation formula:
1.5Xworking load;
Holding load calculation formula:
0.45Xbreaking load of anchor chain;

The above table is the standard configuration, and it can be customized.
